Modified 225 kVp Nikon/Xtek HMX

Home » Facilities » University of Southampton » Modified 225 kVp Nikon/Xtek HMX


This is a custom Nikon Xtek XTH 225 kVp microfocus CT system equipped with a robotic sample exchanger (~ 150 mm height limit). It is perfect for relatively small specimens (< 300 mm in height) that can be scanned using a 225 kVp X-ray source. The source can be configured for high resolution or high flux through a range of different anodes; namely a transmission anode (spot ≥ 1 µm, low flux), a standard multi-material reflection anode (spot ≥ 3 µm, ‘normal’ flux) and a rotating anode (spot ≥ 10 µm, x3 -5 flux). A labyrinth at the rear of the system allows routing of cables and pipes that can control and feed in-situ rigs for time-resolved (4D) µ-CT experiments.


Key Features
  • Three configurations
  • Transmission (~1 µm spot limit, low flux)
  • Standard reflection (~3 µm spot, ‘normal’ flux)
  • Rotating target (~10µm spot limit, x3-5 flux)
  • 2 x 2 k flat panel detector
  • Samples to ~300 mm and 50 kg
  • Robotic sample exchange (~150 mm height limit)
  • Image of a Modified 225 kVp Nikon X-Tek HMX
